Login to the Shelf Manager.
On the Hardware Monitor toolbar select either the Basic Mode or Advanced Mode
diagnostics. Depending on your selection proceed with one of the following sections:

Performing Basic Mode Diagnostics

To run Basic Mode Diagnostics on a Hardware Component:
•
•
1
2
3
Polycom, Inc.
Most of the user interfaces illustrated in this section show the RMX 2000 with MPMx cards. The
Basic Mode for other RMXs with MPM+ card(s) are identical.
On the RMX 1500 less "slots" are used and the module naming conventions used on elements
are different.
In the list pane tool bar, click the Basic Mode (
RMX 2000/4000 &
RMX 1500 Hardware
Monitor panes
In the Reset Confirmation dialog box, click Yes.
The RMX resets. Re-enter the Shelf Manager IP address in the browser and Login under
POLYCOM or with an "Administrator" Login.
Chapter 20-RMX Hardware Monitoring
) button.
