Resolution Configuration

All the above resolution options and settings are based on a decision matrix which matches
video resolutions to connection line rates, with the aim of providing the best balance
between resource usage and video quality at any given line rate.
The Resolution Configuration dialog box enables the RMX administrator to override the
default video resolution decision matrix, effectively creating his/her own decision matrix.
The minimum threshold line rates at which endpoints are connected at the various video
resolutions can be optimized by adjusting the resolution sliders.
System resource usage is also affected by the Resolution Configuration settings. For more
information see "Video Resource Usage" on page
Rates" on page 2-4.

Guidelines

•
On the RMX1500 MPMx-Q assembly, the use of HD with Continuous Presence requires an
additional license. In the Resource Report and Resolution Configuration panes, HD settings are
displayed but are not enabled and if HD is selected the system will enable SD by default.
•
•
•
From Version 7.1, MPM media cards are not supported.

Accessing the Resolution Configuration dialog box

The Resolution Configuration dialog box is accessed by clicking Setup > Resolution
Configuration in the RMX Setup menu.
The Resolution Configuration dialog box display changes according to the Card Configuration
Mode:
•
•
Modifying the Resolution Configuration in MPM or MPM+ Card Configuration
Mode
The Resolution Configuration dialog box shown below is displayed when the RMX is in MPM,
MPM+ or MPMx Card Configuration Mode.
Polycom, Inc.
Resolution Slider settings affect all Continuous Presence (CP) conferences running on the
RMX. Video Switched conferences are not affected.
A system restart is not needed after changing the Resolution Slider settings.
Resolution Slider settings cannot be changed if there are ongoing conferences running on
the RMX.
The displayed sliders and the resolutions change according the Card Configuration Mode:
MPM, MPM+ or MPMx.
MPM and MPM+
MPMx - supports H.264 High Profile
Chapter 2-Additional Conferencing Information
2-4 and "Default Minimum Threshold Line
2-13
