Polycom RMX 1500/2000/4000 Administrator's Guide
3
If you connected to the Hardware Monitoring via the Shelf Management server, the SW Alarm List
section will not be displayed.
To view the Card Properties:
1
20-12
Table 20-9 MCU Properties - Event Log (Continued)
Column
Status
Ipmb Address(hex)
Click the Active Alarms tab to view alarms related to the RMX, i.e. temperatures and
main power sensors.
The Active Alarms dialog box displays fields that relate to faults and errors detected on
the RMX by sensors. The Active Alarms dialog box is divided into two sections: HW
Alarm List and SW Alarm List.
Each section's alarm list can be saved as a *.xls file by clicking the Save HW Alarm List
and Save SW Alarm List buttons respectively. Each alarm list color codes the severity
of the alarm; Critical (RED), Major (ORANGE) and Normal (GREEN).
In the Hardware Monitor pane, either double-click or right-click and select properties for
the desired hardware component.
The following information is displayed:
Table 20-10 Card Properties - General Info
Field
HW Version
SW Version
Serial Number
Card Type
Card Part Number
Description
The sensor's active status.
Contains all the internal IPMI network addresses on the IPMB bus,
i.e. 0x20 (Switch), 0x86 (MFA), etc...
Description
The hardware component's version number.
The version number of the software installed on card.
The hardware component's serial number.
Displays the type of card that occupies the slot.
The part number of the HW component's board.
