MIB Name
MP-MIB (H323-MP.MIB)
MIB-II/RFC1213-MIB
(RFC1213.MIB)
ENTITY-MIB
(ENTITY.MIB)

Traps

Three types of traps are sent as follows:
1
2
Polycom, Inc.
Description
Used to identify objects defined for an H.323 Multipoint Processor, and
consists of two groups: Configuration and Conference. The
Configuration group is used to identify audio/video mix configuration
counts. The Conference group describes the audio and video multi-
processing operation.
Holds basic network information and statistics about the following
protocols: TCP, UDP, IP, ICMP and SNMP. In addition, it holds a table of
interfaces that the Agent has. MIB-II also contains basic identification
information for the system, such as, Product Name, Description,
Location and Contact Person.
Describes the unit physically: Number of slots, type of board in each
slot, and number of ports in each slot.
ColdStart trap. This is a standard trap which is sent when the MCU is reset.
coldStart notification received from: 172.22.189.154 at 5/20/
2007 7:03:12 PM
Time stamp: 0 days 00h:00m:00s.00th
Agent address: 172.22.189.154 Port: 32774 Transport: IP/UDP
Protocol: SNMPv2c Notification
Manager address: 172.22.172.34 Port: 162 Transport: IP/UDP
Community: public
Enterprise: enterprises.8072.3.2.10
Bindings (3)
Binding #1: sysUpTime.0 *** (timeticks) 0 days
00h:00m:00s.00th
Binding #2: snmpTrapOID.0 *** (oid) coldStart
Binding #3: snmpTrapEnterprise.0 *** (oid)
enterprises.8072.3.2.10
Figure 1 An Example of a ColdStart Trap
Authentication failure trap. This is a standard trap which is sent when an unauthorized
community tries to enter.
authentication Failure notification received from:
172.22.189.154 at 5/20/2007 7:33:38 PM
Time stamp: 0 days 00h:30m:27s.64th
Agent address: 172.22.189.154 Port: 32777 Transport: IP/UDP
Protocol: SNMPv2c Notification
Manager address: 172.22.172.34 Port: 162 Transport: IP/UDP
Community: public
Enterprise: enterprises.8072.3.2.10
Bindings (3)
Binding #1: sysUpTime.0 *** (timeticks) 0 days
00h:30m:27s.64th
Binding #2: snmpTrapOID.0 *** (oid) authenticationFailure
Binding #3: snmpTrapEnterprise.0 *** (oid)
enterprises.8072.3.2.10
Figure 2 An Example of an Authentication Failure Trap
