Polycom RMX 1500/2000/4000 Administrator's Guide
Table 20-21
Column
Fail
Status

Cards Monitor

The Cards Monitor tab displays the status of the selected tests being run on the currently
viewed card, i.e. slot 5, described below.
Table 20-22
Column
Unitid
Testname
Loop
Pass
Failed
Quick
Duration
Status
20-34
Tests Monitoring - MCU Monitor Parameters (Continued)
Description
Indicates the number of tests that the card failed.
The card's current test status: No test running or Test in progress.
Tests Monitoring - Card Monitor Parameters
Description
The test ID number
The name of the test
Indicates the number of times the test will repeat itself in succession.
Indicates the number of times the test passed successfully.
Indicates the number of times the test failed.
Indicates the number of Quick tests that have been run on the card.
The duration of the test (in seconds).
The card's current test status: Test in Progress or Ready.
Polycom, Inc.
