Setting The Static Route For Rmx In The Ocs - Polycom RMX 1500 Administrator's Manual

Polycom RMX 1500/2000/4000 Administrator's Guide
5
6
7
8
If routing between the RMX and the OCS using Static Routes is required, do not close this dialog
box, and continue with the following procedure. If you do not want to define Static Routes, click OK
to close this dialog box.

Setting the Static Route for RMX in the OCS

To add RMX to the Routing Roles:
9
10 Click the
H-8
Click the Add button to add the RMX as trusted host.
The Add Authorized Host dialog box opens.
In the Add Authorized Host dialog box, enter the RMX FQDN name as defined in the
DNS and will be used in the Static Routes definition.
In the Settings section, select the Throttle as Server and Treat As Authenticated check
boxes.
Click OK.
The defined RMX appears in the trusted servers list in the server Front End Properties—
Host Authorization dialog box.
In the Front End Properties dialog box, click the Routing tab.
Add
button.
The Add Static Routes dialog box opens.
