Polycom RMX 1500 Administrator's Manual page 31

4
Polycom, Inc.
Table 1-4 New Profile - General Parameters (Continued)
Field/Option
Line Rate
Routing Name
Video Switching
H.264 High Profile
Operator Conference
Click the Advanced tab.
Description
Select the conference bit rate. The line rate represents the combined
video, audio and Content rate.
The default setting is 384 Kbps.
Note: This field is displayed in all tabs.
Enter the Profile name using ASCII characters set.
The Routing Name can be defined by the user or automatically
generated by the system if no Routing Name is entered as follows:
•
If an all ASCII text is entered in Display Name, it is used also as
the Routing Name.
•
If any combination of Unicode and ASCII text (or full Unicode text)
is entered in Display Name, the ID (such as Conference ID) is
used as the Routing Name.
If the Operator Conference option is selected, this option is disabled,
and the selection is cleared.
When selected, the conference is in a special conferencing mode
which implies that all participants must connect at the same line rate
and use the same video resolution. Participants with endpoints that
do not support the selected line rate and resolution will connect as
secondary (audio only).
For more information, see "Video Switching" on page 2-20.
Select the video protocol and resolution:
•
H.264 720p30 (supported by all media cards)
MPM+ and MPMx cards only:
•
H.264 1080p30
•
H.264 720p60
•
H.264 SD 30
Notes:
• High Definition Video Switching conferencing mode is unavailable
to ISDN participants.
Select this check box to enable the use of H.264 High Profile in Video
Switching conferences. For more information, see "Enabling H.264
High Profile in VSW Conferences" on page 2-23.
Select this option to define the profile of an Operator conference.
An Operator conference can only be a Continuous Presence
conference, therefore when selected, the High Definition Video
Switching option is disabled and cleared.
When defining an Operator Conference, the Send Content to Legacy
Endpoints option in the Video Settings tab is cleared and disabled.
For more information, see Chapter 8, "Operator Assistance &
Participant Move" on page 8-1.
Chapter 1-Conference Profiles
1-9
