Automatic Dial String Generation

The administrator can now configure the Gateway Profile to automatically generate and
forward the dial string from the RMX Gateway Session to the DMA in order to connect to the
required DMA Meeting Room. When this configuration option is selected, the participant
does not need to interact with the IVR Service.
Figure 18
Example:
Figure 1 shows the call flow assuming the following parameters:
First Dial-in Number
Last Dial-in Number
Use Dial-in Numbers as Destination ID
PSTN participant dials
Destination Prefix (DMA Gatekeeper)
Number of Rightmost Digits to Append
DMA Meeting Room ID

PSTN Dial-in Using GK Prefix

When connecting to an RMX that is standalone or part of a DMA solution deployment,
PSTN participants are prompted by an IVR message requesting the Destination Conference ID
followed by the # key to be entered using the DTMF input keypad.
Including the Gatekeeper Prefix in the DTMF input string enables PSTN participants to use
the input string when connecting to an RMX whether the RMX is a standalone MCU or part
of a DMA solution deployment.
Enabling PSTN dial-in using GK prefix
The feature is enabled by the USE_GK_PREFIX_FOR_PSTN_CALLS System Flag in
system.cfg. For more information see "System Configuration" on page 19-4.
Polycom, Inc.
Call Flow from ISDN Endpoint to Polycom DMA with Automatically
Generated Forwarded Dial String
5705550
5705560
Selected
(212)5705555
26
4
5555
Chapter 17-Gateway Calls
17-23
