Guidelines

To ensure that conferences can be cascaded and video can be viewed in all conferences the
following guidelines are recommended:
•
•
•
•
•
•

Flags controlling Cascade Layouts

•
•
3-2
Video layout of Conf. B in
window of Conf. A
Video Layouts in Cascaded Conferences
The same version installed on all MCUs participating the cascading topology
The same license installed on all MCUs participating the cascading topology
Same Conference Parameters are defined in the Profile of the conferences participating
in the cascading topology
— Conference line rates should be identical
— Content rate should be identical
— Same encryption settings
DTMF codes should be defined with the same numeric codes in the IVR services
assigned to the cascading conferences
DTMF forwarding is suppressed
The video layout of the link is set to 1x1 by the appropriate system flag.
Setting the FORCE_1X1_LAYOUT_ON_CASCADED_LINK
_CONNECTION System Flag to YES (default) automatically forces the cascading link to
Full Screen (1x1) in CP conferences, hence displaying the speaker of one conference to a
full window in the video layout of the other conference.
Set this flag to NO when cascading between an RMX and an MGC that is functioning as
a Gateway, if the participant layouts on the MGC are not to be forced to 1X1.
Setting the AVOID_VIDEO_LOOP_BACK_IN_CASCADE System Flag to YES
(default) prevents the speaker's image from being sent back through the participant
link from the cascaded conference. This can occur in cascaded conferences with
conference layouts other than 1x1. It results in the speaker's own video image being
displayed in the speaker's video layout.
Guidelines
This option is supported with:
— With MPM+ and MPMx cards.
— In H.323, SIP and ISDN environments.
Video layout of Conf. A in
window of Conf. B
