Polycom RMX 1500/2000/4000 Administrator's Guide
5
Run a "Diagnostics" test on a CTNL card by clicking the CTNL hardware component that indicates
"Diagnostics" in the status column.
6
Optional. In the Diagnostics - Active Test box you can select specific tests to run and then click Run
Selected Tests.
20-32
When the RMX enters "Diagnostics Mode", the status MPM+/MPMx, CNTL/CNTL
1500/CNTL 4000 and RTM IP/RTM IP 1500/RTM IP 4000 changes to "Diagnostics".
You can run "Diagnostics" tests on a MPM+/MPMx card by double clicking any one of
the hardware components indicating "Diagnostics" in the status column.
Figure 20-5 RMX 2000/4000 MPMx D - DSP DSP Sub Test selection
Select the Run all Tests box and then click Run Selected Tests.
Table 20-20 Tests Selection - Additional Test Parameters
Parameter
Loop Test
Stop On Failure
Run All Test
Description
Enter the amount of times the test is to repeat itself in succession.
Stops tests upon a failure.
Runs all tests listed in the TestActive column for the hardware
component.
