Table 31-54: ADSP-SC58x EMAC Register List (Continued)
Name
EMAC_RXOSIZE_G
EMAC_RXPAUSEFRM
EMAC_RXRCV_ERR
EMAC_RXRUNT_ERR
EMAC_RXTCP_ERR_FRM
EMAC_RXTCP_ERR_OCT
EMAC_RXTCP_GD_FRM
EMAC_RXTCP_GD_OCT
EMAC_RXUCASTFRM_G
EMAC_RXUDP_ERR_FRM
EMAC_RXUDP_ERR_OCT
EMAC_RXUDP_GD_FRM
EMAC_RXUDP_GD_OCT
EMAC_RXUSIZE_G
EMAC_RXVLANFRM_GB
EMAC_RXWDOG_ERR
EMAC_SMI_ADDR
EMAC_SMI_DATA
EMAC_TM_ADDEND
EMAC_TM_AUXSTMP_NSEC
EMAC_TM_AUXSTMP_SEC
EMAC_TM_CTL
EMAC_TM_HISEC
EMAC_TM_NSEC
EMAC_TM_NSECUPDT
EMAC_TM_PPS0INTVL
EMAC_TM_PPS0NTGTM
EMAC_TM_PPS0TGTM
EMAC_TM_PPS0WIDTH
EMAC_TM_PPS1INTVL
EMAC_TM_PPS1NTGTM
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
Rx Oversize (Good) Register
Rx Pause Frames Register
Rx Error Frames Received Register
Rx Runt Error Register
Rx TCP Error Frames Register
Rx TCP Error Octets Register
Rx TCP Good Frames Register
Rx TCP Good Octets Register
Rx Unicast Frames (Good) Register
Rx UDP Error Frames Register
Rx UDP Error Octets Register
Rx UDP Good Frames Register
Rx UDP Good Octets Register
Rx Undersize (Good) Register
Rx VLAN Frames (Good/Bad) Register
Rx Watch Dog Error Register
SMI Address Register
SMI Data Register
Time Stamp Addend Register
Time Stamp Auxiliary TS Nano Seconds Register
Time Stamp Auxiliary TM Seconds Register
Time Stamp Control Register
Time Stamp High Second Register
Time Stamp Nanoseconds Register
Time Stamp Nanoseconds Update Register
Time Stamp PPS Interval Register
Time Stamp Target Time Nanoseconds Register
Time Stamp Target Time Seconds Register
PPS Width Register
PPS 1 Interval Register
PPS 1 Target Time Nanoseconds Register
ADSP-SC58x EMAC Register Descriptions
31–117
