DAI Sources Overview
Table 33-16: DAI1 Group C – Frame Sync Signals
Selection Code
00000 (0x0)
00001 (0x1)
00010 (0x2)
00011 (0x3)
00100 (0x4)
00101 (0x5)
00110 (0x6)
00111 (0x7)
01000 (0x8)
01001 (0x9)
01010 (0xA)
01011 (0xB)
01100 (0xC)
01101 (0xD)
01110 (0xE)
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
10011 (0x13)
10100 (0x14)
10101 (0x15)
10110 (0x16)
10111 (0x17)
11000 (0x18)
11001 (0x19)
11010 (0x1A)
11011 (0x1B)
11100 (0x1C)
11101 (0x1D)
11110 (0x1E)
33–36
Source Signal
DAI1_CRS_PB04_O
DAI1_PB02_O
DAI1_PB03_O
DAI1_PB04_O
DAI1_PB05_O
DAI1_PB06_O
DAI1_PB07_O
DAI1_PB08_O
DAI1_PB09_O
DAI1_PB10_O
DAI1_PB11_O
DAI1_PB12_O
DAI1_PB13_O
DAI1_PB14_O
DAI1_PB15_O
DAI1_PB16_O
DAI1_PB17_O
DAI1_PB18_O
DAI1_PB19_O
DAI1_PB20_O
SPT4_AFS_O
SPT4_BFS_O
SPT5_AFS_O
SPT5_BFS_O
SPT6_AFS_O
SPT6_BFS_O
SPDIF1_FS_O
Reserved
PCG0_FSC_O
PCG0_FSD_O
LOW
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description (Source Selection)
Pin Buffer 4 (DAI0)
Pin Buffer 2
Pin Buffer 3
Pin Buffer 4
Pin Buffer 5
Pin Buffer 6
Pin Buffer 7
Pin Buffer 8
Pin Buffer 9
Pin Buffer 10
Pin Buffer 11
Pin Buffer 12
Pin Buffer 13
Pin Buffer 14
Pin Buffer 15
Pin Buffer 16
Pin Buffer 17
Pin Buffer 18
Pin Buffer 19
Pin Buffer 20
SPORT 4 Frame Sync A
SPORT 4 Frame Sync B
SPORT 5 Frame Sync A
SPORT 5 Frame Sync B
SPORT 6 Frame Sync A
SPORT 6 Frame Sync B
SPDIF 1 RX Frame Sync Output
Precision Frame Sync C Output
Precision Frame Sync D Output
Logic Level Low (0)
