DAI Sources Overview
Table 33-12: DAI0 Group E – Miscellaneous Signals
Selection Code
00000 (0x0)
00001 (0x1)
00010 (0x2)
00011 (0x3)
00100 (0x4)
00101 (0x5)
00110 (0x6)
00111 (0x7)
01000 (0x8)
01001 (0x9)
01010 (0xA)
01011 (0xB)
01100 (0xC)
01101 (0xD)
01110 (0xE)
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
10011 (0x13)
10100 (0x14)
10101 (0x15)
10110 (0x16)
10111 (0x17)
11000 (0x18)
11001 (0x19)
11010 (0x1A)
11011 (0x1B)
11100 (0x1C)0
11101 (0x1D)
11110 (0x1E)
33–30
Source Signal
DAI0_PB01_O
DAI0_PB02_O
DAI0_PB03_O
DAI0_PB04_O
DAI0_PB05_O
DAI0_PB06_O
DAI0_PB07_O
DAI0_PB08_O
DAI0_PB09_O
DAI0_PB10_O
DAI0_PB11_O
DAI0_PB12_O
DAI0_PB13_O
DAI0_PB14_O
DAI0_PB15_O
DAI0_PB16_O
DAI0_PB17_O
DAI0_PB18_O
DAI0_PB19_O
DAI0_PB20_O
SPT0_AFS_O
SPT0_BFS_O
SPT1_AFS_O
SPT1_BFS_O
SPT2_AFS_O
SPT2_BFS_O
SPDIF0_TX_BLKSTART_O
PCG0_FSA_O
PCG0_CLKB_O
PCG0_FSB_O
LOW
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description (Source Selection)
Pin Buffer 1 Output
Pin Buffer 2 Output
Pin Buffer 3 Output
Pin Buffer 4 Output
Pin Buffer 5 Output
Pin Buffer 6 Output
Pin Buffer 7 Output
Pin Buffer 8 Output
Pin Buffer 9 Output
Pin Buffer 10 Output
Pin Buffer 11 Output
Pin Buffer 12 Output
Pin Buffer 13 Output
Pin Buffer 14 Output
Pin Buffer 15 Output
Pin Buffer 16 Output
Pin Buffer 17 Output
Pin Buffer 18 Output
Pin Buffer 19 Output
Pin Buffer 20 Output
SPORT 0 Frame Sync A
SPORT 0 Frame Sync B
SPORT 1 Frame Sync A
SPORT 1 Frame Sync B
SPORT 2 Frame Sync A
SPORT 2 Frame Sync B
SPDIF 0 TX Block Start Output
Precision Frame Sync A
Precision Clock B
Precision Frame Sync B
Logic Level Low (0) as a Source
