Analog Devices ADSP-SC58 Series Hardware Reference Manual page 2526

(Amplitude) Limits for Secondary Filter 1 Register
The register controls amplitude limits for a secondary filter of SINC pair 1.
SINC_LIMIT1
Figure 32-14: SINC_LIMIT1 Register Diagram
Table 32-15: SINC_LIMIT1 Register Fields
Bit No.
(Access)
31:16 LMAX
(R/W)
15:0 LMIN
(R/W)
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
15 14 13
0 0 0
LMIN (R/W)
Limit Minimum for Secondary Filter 1
31 30 29
0 0 0
LMAX (R/W)
Limit Maximum for Secondary Filter 1
Bit Name
Limit Maximum for Secondary Filter 1.
The SINC_LIMIT1.LMAX bits specify the output signal conditions for the secon-
dary SINC filter 1. In conjunction with bits LCNT and LWIN in register
SINC_LEVEL1
ed maximum limit warning bit in register SINC_STAT.
Limit Minimum for Secondary Filter 1.
The SINC_LIMIT1.LMIN bits specify the output signal conditions for the secon-
dary SINC filter 1. In conjunction with bits LCNT and LWIN in register
SINC_LEVEL1
ed minimum limit warning bit in register SINC_STAT.
12 11 10 9 8 7 6 5
0 0 0 0 0 0 0 0
28 27 26 25 24 23 22 21
0 0 0 0 0 0 0 0
Description/Enumeration
or SINC_LEVEL0, this bit field specifies conditions for an associat-
or SINC_LEVEL0, this bit field specifies conditions for an associat-
ADSP-SC58x SINC Register Descriptions
4 3 2 1 0
0 0 0 0 0
20 19 18 17 16
0 0 0 0 0
32–35
