DAI Destination Registers Overview
Table 33-20: Clock Destination Registers (Group A) (Continued)
DAI Register Bit Field
Name
DAI_CLK5 IN0
IN1
Table 33-21: Data Destination Registers (Group B)
DAI Regis- Bit Field
ter Name
DAI_DAT0 IN0
IN1
IN2
IN3
IN4
DAI_DAT1 IN0
IN1
IN2
IN3
IN4
DAI_DAT2 IN0
IN1
IN2
IN3
IN4
33–44
DAI0 Mapping
SPT3_ACLK_I
SPT3_BCLK_I
DAI0 Mapping
SPT0_AD0_I
SPT0_AD1_I
SPT0_BD0_I
SPT0_BD1_I
SPT1_AD0_I
SPT1_AD1_I
SPT1_BD0_I
SPT1_BD1_I
SPT2_AD0_I
SPT2_AD1_I
SPT2_BD0_I
SPT2_BD1_I
SRC0_DAT_IP_I
SRC1_DAT_IP_I
SRC2_DAT_IP_I
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
DAI1 Mapping
SPT7_ACLK_I
SPT7_BCLK_I
DAI1 Mapping
SPT4_AD0_I
SPT4_AD1_I
SPT4_BD0_I
SPT4_BD1_I
SPT5_AD0_I
SPT5_AD1_I
SPT5_BD0_I
SPT5_BD1_I
SPT6_AD0_I
SPT6_AD1_I
SPT6_BD0_I
SPT6_BD1_I
SRC4_DAT_IP_I
SRC5_DAT_IP_I
SRC6_DAT_IP_I
Description
SPORT3A or SPORT 7A Clock
SPORT3B or SPORT 7B Clock
Description
SPORT0A or SPORT4A Primary Data
SPORT0A or SPORT4A Secondary
Data
SPORT0B or SPORT4B Primary Data
SPORT0B or SPORT4B Secondary
Data
SPORT1A or SPORT5A Primary Data
SPORT1A or SPORT5A Secondary
Data
SPORT1B or SPORT5B Primary Data
SPORT1B or SPORT5B Secondary
Data
SPORT2A or SPORT6A Primary Data
SPORT2A or SPORT6A Secondary
Data
SPORT2B or SPORT6B Primary Data
SPORT2B or SPORT6B Secondary
Data
SRC0 or SRC4 Data
SRC1 or SRC5 Data
SRC2 or SRC6 Data
