Analog Devices ADSP-SC58 Series Hardware Reference Manual page 2597

DAI Destination Registers Overview
Table 33-22: Frame Sync Destination Registers (Group C) (Continued)
DAI Register Bit Field
Name
IN5
DAI_FS2 IN0
IN1
IN2
DAI_FS4 IN0
IN1
Table 33-23: Pin Buffer Assignment Destination Registers (Group D)
DAI Register Bit Field
Name
DAI_PIN0 IN0
IN1
IN2
IN3
DAI_PIN1 IN0
IN1
IN2
IN3
DAI_PIN2 IN0
IN1
IN2
IN3
DAI_PIN3 IN0
IN1
IN2
IN3
DAI_PIN4 IN0
IN1
IN2
IN3
IN4
33–46
DAI0 Mapping DAI1 Mapping
SRC2_FS_OP_I SRC6_FS_OP_I
SRC3_FS_IP_I SRC7_FS_IP_I
SRC3_FS_OP_I SRC7_FS_OP_I
SPDIF0_TX_FS_I SPDIF1_TX_FS_I
SPT3_AFS_I SPT7_AFS_I
SPT3_BFS_I SPT7_BFS_I
DAI0 Mapping DAI1 Mapping
DAI0_PB01_I DAI1_PB01_I
DAI0_PB02_I DAI1_PB02_I
DAI0_PB03_I DAI1_PB03_I
DAI0_PB04_I DAI1_PB04_I
DAI0_PB05_I DAI1_PB05_I
DAI0_PB06_I DAI1_PB06_I
DAI0_PB07_I DAI1_PB07_I
DAI0_PB08_I DAI1_PB08_I
DAI0_PB09_I DAI1_PB09_I
DAI0_PB10_I DAI1_PB10_I
DAI0_PB11_I DAI1_PB11_I
DAI0_PB12_I DAI1_PB12_I
DAI0_PB13_I DAI1_PB13_I
DAI0_PB14_I DAI1_PB14_I
DAI0_PB15_I DAI1_PB15_I
DAI0_PB16_I DAI1_PB16_I
DAI0_PB17_I DAI1_PB17_I
DAI0_PB18_I DAI1_PB18_I
DAI0_PB19_I DAI1_PB19_I
DAI0_PB20_I DAI1_PB20_I
INV_DAI0_PB19_I INV_DAI1_PB19_I
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
SRC2 or SRC6 Frame Sync Output
SRC3 or SRC7 Frame Sync Input
SRC3 or SRC7 Frame Sync Output
SPDIF0 or SPDIF1 Transmit Frame
Sync
SPORT3A or SPORT7A Frame Sync
SPORT3B or SPORT7B Frame Sync
Description
Pin Buffer 1
Pin Buffer 2
Pin Buffer 3
Pin Buffer 4
Pin Buffer 5
Pin Buffer 6
Pin Buffer 7
Pin Buffer 8
Pin Buffer 9
Pin Buffer 10
Pin Buffer 11
Pin Buffer 12
Pin Buffer 13
Pin Buffer 14
Pin Buffer 15
Pin Buffer 16
Pin Buffer 17
Pin Buffer 18
Pin Buffer 19
Pin Buffer 20
Inverted Pin Buffer 19
