Table 33-11: DAI0 Group D – Pin Signal Assignments
Selection Code
0000000 (0x0)
0000001 (0x1)
0000010 (0x2)
0000011 (0x3)
0000100 (0x4)
0000101 (0x5)
0000110 (0x6)
0000111 (0x7)
0001000 (0x8)
0001001 (0x9)
0001010 (0xA)
0001011 (0xB)
0001100 (0xC)
0001101 (0xD)
0001110 (0xE)
0001111 (0xF)
0010000 (0x10)
0010001 (0x11)
0010010 (0x12)
0010011 (0x13)
0010100 (0x14)
0010101 (0x15)
0010110 (0x16)
0010111 (0x17)
0011000 (0x18)
0011001 (0x19)
0011010 (0x1A)
0011011 (0x1B)
0011100 (0x1C)
0011101 (0x1D)
0011110 (0x1E)
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Source Signal
DAI0_PB01_O
DAI0_PB02_O
DAI0_PB03_O
DAI0_PB04_O
DAI0_PB05_O
DAI0_PB06_O
DAI0_PB07_O
DAI0_PB08_O
DAI0_PB09_O
DAI0_PB10_O
DAI0_PB11_O
DAI0_PB12_O
DAI0_PB13_O
DAI0_PB14_O
DAI0_PB15_O
DAI0_PB16_O
DAI0_PB17_O
DAI0_PB18_O
DAI0_PB19_O
DAI0_PB20_O
SPT0_AD0_O
SPT0_AD1_O
SPT0_BD0_O
SPT0_BD1_O
SPT1_AD0_O
SPT1_AD1_O
SPT1_BD0_O
SPT1_BD1_O
SPT2_AD0_O
SPT2_AD1_O
SPT2_BD0_O
DAI Sources Overview
Description (Source Selection)
Pin Buffer 1
Pin Buffer 2
Pin Buffer 3
Pin Buffer 4
Pin Buffer 5
Pin Buffer 6
Pin Buffer 7
Pin Buffer 8
Pin Buffer 9
Pin Buffer 10
Pin Buffer 11
Pin Buffer 12
Pin Buffer 13
Pin Buffer 14
Pin Buffer 15
Pin Buffer 16
Pin Buffer 17
Pin Buffer 18
Pin Buffer 19
Pin Buffer 20
SPORT 0 Data AD0
SPORT 0 Data AD1
SPORT 0 Data BD0
SPORT 0 Data BD1
SPORT 1 Data AD0
SPORT 1 Data AD1
SPORT 1 Data BD0
SPORT 1 Data BD1
SPORT 2 Data AD0
SPORT 2 Data AD1
SPORT 2 Data BD0
33–27
