9-8
Command Diagnostic Messages
C1400 Command Get marker position
C1700 Command measuring wheel mode
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
Supported by Firmware Variant:
The P-0-0014, C1400 Command Get marker position command was
started.
The "C14" display signals that the command is executed.
In the case of incremental measuring systems, the reference mark is
checked for correct detection.
See also Functional Description "Detect marker position"
C1400 - Attributes
Display:
C14
Mess. no.:
C1400 (hex)
Supported by Firmware Variant:
The P-0-0240, C1700 Command measuring wheel mode was started.
C1700 - Attributes
Display:
C17
Mess. no.:
C1700 (hex)
Rexroth IndraDrive
FWA-INDRV*-MPH02VRS-MS
FWA-INDRV*-MPB02VRS-MS
FWA-INDRV*-MPD02VRS-MS
FWA-INDRV*-MPH02VRS-MS
FWA-INDRV*-MPB02VRS-MS
FWA-INDRV*-MPD02VRS-MS
DOK-INDRV*-GEN-**VRS**-WA01-EN-P
