inverters
Goodrive35
Function
code
UP terminals frequency
P08.45
changing ratio
DOWN terminals
P08.46
frequency changing ratio
P17.00 Setting frequency
P17.02 Ramp reference frequency
P17.14 Digital adjustment

7.9 Analog input

Goodrive35 series inverters have three analog input terminals and 1 high-speed pulse input
terminals (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input
by J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
Name Detailed instruction of parameters
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after
receiving the stop commands
0.01~50.00 Hz/s
0.01~50.00 Hz/s
Display current set frequency of the
inverter
Range: 0.00Hz~P00.03
Display current ramp given frequency of
the inverter
Range: 0.00Hz~P00.03
Display the adjustment through the
keypad of the inverter.
Range : 0.00Hz~P00.03
205
www.barghmaher.ir
Basic operation instruction
Default
value
0.50 Hz/s
0.50 Hz/s
0.00Hz
0.00Hz
0.00Hz
