The below table is the option of the four function parameters and selecting the repeated output
terminal function is allowed.
Set value
0
1
2 Forward running
3 Reverse running
4
5 Inverter fault
6
7
8 Frequency arrival
9 Zero-speed running
10 Upper-limit frequency arrival
11 Upper-limit frequency arrival
12
13 Pre-exciting
14 Overload pre-alarm
15 Underload pre-alarm
Function
Invalid The output terminal has no function.
Output ON signal when the inverter is running and
Running
there is frequency output.
Output ON signal when the inverter is running
forward and there is frequency output.
Output ON signal when the inverter is running
reverse and there is frequency output.
Output ON signal when the inverter is jogging and
Jogging
there is frequency output.
Output ON signal when the inverter is in fault
Please refer to P08.32 and P08.33 for detailed
FDT1
information.
Please refer to P08.34 and P08.35 for detailed
FDT2
information.
Please refer to P08.36 for detailed information.
Output ON signal when the output frequency and
given frequency of the inverter is 0 at the same time.
Output ON signal when the running frequency of the
inverter is the upper limit frequency.
Output ON signal when the running frequency of the
inverter is the lower limit frequency.
When the main circuit and the control circuit are
established and the protection function of the inverter
Ready
is not active. The inverter is in the running state and it
will output ON signal.
Output ON signal when the inverter is in the
pre-exciting state.
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.08~P11.10 for the
detailed instruction.
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.11~P11.12 for the
detailed instruction.
