Rated Specifications - INVT Goodrive 35 Series Operation Manual

inverters
Goodrive35
Key Sign
Lot number
④

3.6 Rated specifications

3.6.1 The inverters of AC 3PH 380V(-15%)~440V(+10%)
Model
GD35-1R5G-4-C1/D1/H1
GD35-2R2G-4-C1/D1/H1
GD35-004G-4-C1/D1/H1/H2
GD35-5R5G-4-C1/D1/H1/H2
GD35-7R5G-4-C1/D1/H1/H2
GD35-011G-4-C1/D1/H1/H2
GD35-015G-4-C1/D1/H1/H2
GD35-018G-4-C1/D1/H1/H2
GD35-022G-4-C1/D1/H1/H2
GD35-030G-4-C1/D1/H1/H2
GD35-037G-4-C1/D1/H1
GD35-045G-4-C1/D1/H1
GD35-055G-4-C1/D1/H1
GD35-075G-4-C1/D1/H1
GD35-090G-4-C1/D1/H1
Instruction
Rated voltage:660V
C1: support 24V incremental encoder
D1: support rotary transformer
Optional PG cards with functions of pulse and
direction pulse input reference
H1: support 5V/12V incremental encoder,
Lot number
Pulse + direction pulse input reference
H2: support 5V incremental encoder for high
speed differential signal processing,
Pulse + direction pulse input reference (special
for machine tools)
Rated
output
power(kW)
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
18
www.barghmaher.ir
Product overview
Content
Rated Rated
input output
current(A) current(A)
5.0 3.7
5.8 5
13.5 9.5
19.5 14
25 18.5
32 25
40 32
47 38
56 45
70 60
80 75
94 92
128 115
160 150
190 180
Model
1~15(8)
1~15(8)
1~15(8)
1~15(8)
1~15(8)
1~1s5(8)
1~15(4)
1~15(4)
1~15(4)
1~15(4)
1~15(4)
1~15(4)
1~15(4)
1~15(2)
1~15(2)
