INVT Goodrive 35 Series Operation Manual page 140

inverters
Goodrive35
Function
Name
code
resistor of
synchrono
us motor 2
Direct axis
inductance
P12.21 of 0.01~655.35mH
synchrono
us motor 2
Quadratur
e axis
inductance
P12.22 0.01~655.35mH
of
synchrono
us motor 2
When P00.15=2, the set
value of P12.23 cannot be
updated by autotuning,
please count according to
Back EMF
the following method.
constant of
P12.23 The counter-electromotive
synchrono
force constant can be
us motor 2
counted according to the
parameters on the name
plate of the motor. There are
three ways to count:
Detailed instruction of parameters
standard principles, if
the gap between the
motor and the
standard one is huge,
the features of the
inverter will decrease.
Note: reset the rated
power of the
motor(P12.15),initializ
e the motor parameter
of P12.16~ P12.19.
After finish the motor
parameter autotuning,
the set value of
P12.20~P12.22 will
renew automatically.
These parameters are
basic parameters
controlled by vectors
which directly impact
the features.
When P00.15=1, the
set value of P12.23
can be updated
through autotuning
automatically, and
there is no need to
change the value of
P12.23; when
P00.15=2, the set
value of P12.23 can
not be updated
through autotuning,
139
