INVT Goodrive 35 Series Operation Manual page 198

inverters
Goodrive35
during normal powering on, start after the restarting function becomes valid during normal
powering on and start after the automatic fault reset. Below is the detailed instruction for three
starting.
There are three starting modes for the inverter: start from the starting frequency directly, start after
the AC braking and start after the rotation speed tracking. The user can select according to
different situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is
better to select starting after DC braking and then starting after rotation speed tracking.
Note: It is recommended to use the direct starting to drive synchronous motor.
The starting logic figure of starting after the running command during the normal powering on.
P01.00
The starting frequency
Starting running
0
N 1
Jogging running
2
The braking current before starting
Y
P08.06
Jogging running frequency
2. The starting logic figure of starting after the restarting function becomes valid during the normal
powering on.
0
Restart after
the power off
1
The waiting time of the restarting
after power off >P01.22
P01.21
restarting after the power off
selection
Start directly
P00.03
Start directly
The starting frequency
The retention time
0
Start after DC braking
P01.05
ACC/DEC method selection
1
P00.03
The braking time before starting
Start after rotation speed tracking
1f
1t
P08.07 P08.08
ACC time DEC time
Stand by
N
N
Y
The retention time of the
restarting
>P01.123
www.barghmaher.ir
Basic operation instruction
Linear ACC/DEC
1f
1t
P00.11 P00.12
ACC time DEC time
Jumping
frequency3
Jumping
frequency 2
Jumping
1f
S curve ACC/DEC
frequency1
1t
P00.11 P00.12
ACC time DEC time
Keypad
0
The running state before
Comm
unicati
Y
on
2
Terminal FWD/REV
1
Whether the running command terminal
is valid
P00.01
Running command channel
197
1f
1/2*jumping range 3
1/2*jumping range 3
1/2*jumping range 2
1/2*jumping range 2
1/2*jumping range 1
1/2*jumping range 1
1t
Running
Running
Stoppin
g
stopping
power off
N
0
Y
1
Running
P01.18
(the running protection of the powering on
terminal selection)
