1.4 Safety guidelines

 Only qualified electricians are allowed to operate on the inverter.
 Do not carry out any wiring and inspection or changing components when
the power supply is applied. Ensure all input power supply is disconnected
before wiring and checking and always wait for at least the time designated
on the inverter or until the DC bus voltage is less than 36V. Below is the table
of the waiting time:
380V
380V
660V
660V
660V
 Do not refit the inverter unauthorizedly; otherwise fire, electric shock or other
injury may occur.
 The base of the radiator may become hot during running. Do not touch to
avoid hurt.
 The electrical parts and components inside the inverter are electrostatic.
Take measurements to avoid electrostatic discharge during relevant
operation.
1.4.1 Delivery and installation
 Please install the inverter on fire-retardant material and keep the inverter
away from combustible materials.
 Connect the braking optional parts (braking resistors, braking units or
Name
Damage to the PCBA board may
occur if not follow the relative
discharge
requirements
Sides of the device may become
Hot sides
hot. Do not touch.
Physical hurt may occur if not follow
Note
the relative requirements
Inverter module
1.5kW-110kW
132 kW -315 kW
22kW-132kW
160kW-350kW
400kW-630kW
6
www.barghmaher.ir
Safety precautions
Instruction
Minimum waiting time
5 minutes
15 minutes
5 minutes
15 minutes
25 minutes
Abbreviation
Note
