INVT Goodrive 35 Series Operation Manual page 61

inverters
Goodrive35
Function
Name
code
source command
2: A+B, the current frequency setting is A frequency
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note:The combination manner can be shifted by
P5(terminal function)
When A and B frequency commands are selected as
"keypad setting", the value of the function code is the
Keypad set
P00.10 original setting one of the frequency data of the
frequency
inverter.
Setting range:0.00 Hz~P00.03(the Max. frequency)
ACC time means the time needed if the inverter
speeds up from 0Hz to the Max. One (P00.03).
ACC time
P00.11
DEC time means the time needed if the inverter
1
speeds down from the Max. Output frequency to 0Hz
(P00.03).
Goodrive35 series inverters define four groups of
ACC/DEC time which can be selected by P05. The
DEC time
factory default ACC/DEC time of the inverter is the
P00.12
1
first group.
Setting range of P00.11 and P00.12:0.0~3600.0s
0: Runs at the default direction, the inverter runs in
the forward direction. FWD/REV indicator is off.
1: Runs at the reverse direction, the inverter runs in
Running
P00.13 the reverse direction. FWD/REV indicator is on.
direction
Modify the function code to shift the rotation direction
of the motor. This effect equals to the shifting the
rotation direction by adjusting either two of the motor
Detailed instruction of parameters
60
www.barghmaher.ir
Function codes
Default
Modify
value
50.00
○
Hz
Depend
○
on
model
Depend
○
on
model
○
0
