INVT Goodrive 35 Series Operation Manual page 135

inverters
Goodrive35
Function
Name
code
rated current of the inverter
LED tens:
0:The inverter continues to work after underload
pre-alarm
1:The inverter continues to work after underload
pre-alarm and the inverter stops to run after overload
fault
2: The inverter continues to work after overload
pre-alarm and the inverter stops to run after
underload fault
LED hundreds :
0:Detection all the time
1:Detection in constant running
Setting range of P11.09: P11.11~200%
Setting range of P11.10: 0.1~3600.0s
Underload
P11.11 pre-alarm If the inverter current or the output current is lower
detection than P11.11, and its lasting time is beyond P11.12,
Underload the inverter will output underload pre-alarm.
pre-alarm Setting range of P11.11: 0~P11.09
P11.12
Setting range of P11.12: 0.1~3600.0s
detection
time
Select the action of fault output terminals on
undervoltage and fault reset.
0x00~0x11
Output
LED ones:
terminal
P11.13 0:Action under fault undervoltage
action
1:No action under fault undervoltage
during fault
LED tens:
0:Action during the automatic reset
1:No action during the automatic reset
Speed 0.0~50.0%
P11.14
deviation Set the speed deviation detection time
Detailed instruction of parameters
134
www.barghmaher.ir
Function codes
Default
Modify
value
○
50%
○
1.0s
○
0x00
●
10.0%
