Goodrive200 inverters
Function
code
Keypad data potentiometer
P08.43
UP/DOWN terminals
P08.44
UP terminals frequency
P08.45
increasing integral ratio
P08.46
frequency integral ratio
P17.00
Ramp reference frequency
P17.02
P17.14

7.9 Analog input

Goodrive200 series inverters have three analog input terminals and 1 high-speed pulse input
terminals (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input
by J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
Name
integral ratio
control
DOWN terminals
Set frequency
Digital adjustment
Detailed instruction of parameters
0.01~10.00s
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting valid
1:UP/DOWN terminals setting valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:All frequency means are valid
2:When the multi-step are priority, it is
invalid to the multi-step
LED hundreds: action selection when
stop
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after
receiving the stop commands
0.01~50.00Hz/s
0.01~50.00 Hz/s
0.00Hz~P00.03
(the Max. output frequency)
0.00Hz~P00.03
(the Max. output frequency)
0.00Hz~P00.03
161
Basic operation instruction
Default
value
0.10s
0x000
0.50 Hz/s
0.50 Hz/s
0.00Hz
0.00Hz
0.00Hz
