Goodrive35 inverters
4.4.5.3 The terminal
Terminal name (CNC)
A2+, A2-, B2+, B2-
AO+, AO-, BO+, BO-, ZO+, ZO-
CME, COM
S7, S8
Terminal name (ENCODER)
+5V, GND
A1+, A1-, B1+, B1-, Z1+, Z1-
U+, U-, V+, V-, W+, W-
Note: refer to section 4.4.1 for detailed information of AO1, AO2, AI1, AI2, 485 and other
terminals.
5V differential pulse+direction reference signal,
Maximum supporting frequency 400 kHz
Encoder signal output, 5V differential signal and the
ratio of frequency-division is 1:1
Alarm output(If use this function, it is necessary to
short-connect Y terminal and +24V terminal, and
remove the tag between CME and COM terminal)
Common switch input (be used as running and clear
signal)
Encoder power supply, to support 5V± 5%, 200mA
power
The encoder differential input signal, Maximum
supporting frequency 400 kHz
Difference angle input signal input of UVW encoders
(not for incremental encoders)
42
www.barghmaher.ir
Installation guidelines
Instruction
Instruction
