INVT Goodrive 35 Series Operation Manual page 101

inverters
Goodrive35
Function
Name
code
25: Ramp reference frequency
26: Operation speed
Lower
The above function codes define the relative
P06.17 output limit
relationship between the output value and analog
of AO1
output. When the output value exceeds the range of
Correspon
set maximum or minimum output, it will count
ding AO1
according to the low-limit or upper-limit output.
P06.18
output of
When the analog output is current output, 1mA
lower limit
equals to 0.5V.
Upper In different cases, the corresponding analog output
P06.19 output limit
of 100% of the output value is different. See each
of AO1
application for detailed information. Please refer to
Analog output in chapter 7 for more details.
The
correspond
P06.20 ing AO1
output of
upper limit
AO1
Setting range of P06.17:-300.0%~P06.19
P06.21 output filter
Setting range of P06.18:0.00V~10.00V
time
Setting range of P06.19:P06.17~300.0%
Lower
Setting range of P06.20:0.00V~10.00V
P06.22 output limit
Setting range of P06.21:0.000s~10.000s
of AO2
Setting range of P06.22: -300.0%~P06.24
Correspon Setting range of P06.23:0.00V~10.00V
Setting range of P06.24: P06.22~300.0%
ding AO2
P06.23
output of Setting range of P06.25:0.00V~10.00V
lower limit Setting range of P06.26:0.000s~10.000s
Setting range of P06.27: -300.0%~P06.29
Upper
Setting range of P06.28:0.00~50.00kHz
P06.24 output limit
Setting range of P06.29: P06.27~300.0%
of AO2
Setting range of P06.30:0.00~50.00kHz
P06.25 The
Detailed instruction of parameters
AO
10V (20mA)
0.0%
100
