Function
Name
code
The setting range of P03.04:0.000~10.000s
The setting range of P03.05:P03.02~P00.03(the
Max. output frequency)
Speed
P03.06 loop output 0~8 (corresponds to 0~2
filter
Compensa
tion
coefficient
P03.07
Slip compensation coefficient is used to adjust the
of
slip frequency of the vector control and improve the
electromoti
speed control accuracy of the system. Adjusting the
on slip
parameter properly can control the speed
Compensa
steady-state error.
tion
Setting range:50%~200%
P03.08 coefficient
of braking
slip
Current
Note:
loop
1 These two parameters adjust the PI adjustment
P03.09 percentage
parameter of the current loop which affects the
coefficient
dynamic response speed and control accuracy
P
directly. Generally, users do not need to change the
Current
default value.
loop
2 Only apply to the vector control mode without PG
P03.10 integral
0(P00.00=0).
coefficient
Setting range: 0~20000
1
This parameter is used to enable the torque control
mode, and set the torque.
Torque 0:Torque control is invalid
P03.11 setting 1:Keypad setting torque(P03.12)
method 2:Analog AI1 setting torque
3:Analog AI2 setting torque
4:Analog AI3 setting torque
Detailed instruction of parameters
8
/10ms)
