INVT Goodrive 35 Series Operation Manual page 156

inverters
Goodrive35
Function
Name
code
Display of Z pulse direction. When the spindle stops,
the stopping position of forward and reverse rotation
may have a deviation of a few pulses. After adjusting
Reverse
P18.11 the direction of Z pulse or the AB phase of encoder,
of Z pulse
the stopping position will be same.
0: Forward
1: Reverse
Z pulse
Reserved
P18.12
angle
0~359.99
Fault
Reserved
P18.13 times of Z
0~65535
pulse
High bit of
After power on, the value will be counted continuously.
Pg1
P18.14
0~65535
counting
Low bit of
After power on, the value will be counted continuously.
P18.15 Pg1
0~65535
counting
Pulse frequency is convertered into setting frequency
Spare
and keeps valid in pulse position mode and pulse
P18.16
variable
speed mode
0~65535
Forward feedback frequency converted from the pulse
Pulse
command forward feedback in pulse and position
command
P18.17
mode
frequency
0.0~400.0Hz
Pulse
The position regulator output frequency in position
command
P18.18
control.
forward
0.0~400.0Hz
feedback
Position
Rotary transformer counting, 0~1024
P18.19 regulator
0.00~400.00Hz
output
Detailed instruction of parameters
155
