INVT Goodrive 35 Series Operation Manual page 84

inverters
Goodrive35
Function
Name
code
V/F
frequency
P04.05
2 of motor
1
V/F
P04.06 voltage 2
of motor 1
When P04.00 =1, the user can set V//F curve
V/F
through P04.03~P04.08.
frequency
P04.07
V/F is generally set according to the load of the
3 of motor
motor.
1
Note:V1＜V2＜V3,f1＜f2＜f3. Too high low
frequency voltage will heat the motor excessively or
cause damage. The inverter may stall when
overcurrent or overcurrent protection.
The setting range of P04.03: 0.00Hz~P04.05
The setting range of P04.04:0.0%~110.0%
V/F
The setting range of P04.05:P04.03~ P04.07
P04.08 voltage 3
The setting range of P04.06:0.0%~110.0%(the rated
of motor 1
voltage of motor 1)
The setting range of P04.07:P04.05~ P02.02(the
rated frequency of motor 1) or P04.05~ P02.16(the
rated frequency of motor 1)
The setting range of P04.08:0.0%~110.0%(the rated
voltage of motor 1)
This function code is used to compensate the
change of the rotation speed caused by load during
V/F slip compensation SVPWM control to improve the rigidity
compensat of the motor. It can be set to the rated slip frequency
P04.09
ion gain of of the motor which is counted as below:
motor 1
Of which, f
function code is P02.02; n is the rated rotating speed
Detailed instruction of parameters
△f=f
-n*p/60
b
is the rated frequency of the motor, its
b
83
www.barghmaher.ir
Function codes
Default
Modify
value
0.00
○
Hz
○
0.0%
0.00
○
Hz
○
0.0%
100.0
○
%
