INVT Goodrive 35 Series Operation Manual page 316

inverters
Goodrive35
Model
1.5kW~2.2kW
4kW~5.5kW
7.5kW~11kW
15kW~18.5kW
22kW~30kW
37kW~55kW
75kW~110kW
132kW~200kW
220kW~315kW
C.4.2 Flange installation
Wall installation of 380V 220-315kW inverters
Installation dimension (unit:mm)
W1 W2
126 115
146 131
170 151
230 210
255 237
270 130
325 200
500 180
680 230
Flange installation of 380V 1.5-30kW inverters
315
www.barghmaher.ir
H1 H2
193 175
263 243.5
331.5 303.5
342 311
407 384
555 540
680 661
870 850
960 926
Appendix C
Installation
D1
hole
174.5 5
181 6
6
216
6
216
7
245
325 7
365 9.5
360 11
380 13
