State word (SW):
The first word of PZD response message is state word (SW) of inverter, the definition of state
word is as follows:
State Word (SW) of Goodrive35 (SW)
Bit Name
0~7 RUN STATE BYTE
8 DC VOLTAGE ESTABLISH
MOTOR GROUP
9~10
FEEDBACK
11 MOTOR TYPE FEEDBACK
12 OVERLOAD ALARM
13
RUN/STOP MODE
14
15 HEARTBEAT FEEDBACK
Actual value (ACT):
nd th
From 2 word to 12 of PZD task message is main set value ACT, main frequency set value
is offered by main setting signal source.
Actual value of Goodrive35
Name
Value
1 Forward running
2 Reverse running
3 The inverter stops
4 The inverter is in fault
5 The inverter is in POFF state
6 Pre-exciting state
1 Running ready
0 The running preparation is not ready
0 Motor 1 feedback
1 Motor 2 feedback
2 Motor 3 feedback
3 Motor 4 no feedback
1 Synchronous motor
0 Asynchronous motor
1 Overload pre-alarm
0 Non-overload pre-alarm
0 Keypad control
1 Terminal control
2 Communication control
3 Reserved
1 Heartbeat feedback
0 No heartbeat feedback
