INVT Goodrive 35 Series Operation Manual page 196

inverters
Goodrive35
Function
code
synchronous motor 1
Number of poles pairs for
P02.17
synchronous motor 1
Rated voltage of
P02.18
synchronous motor 1
Rated current of
P02.19
synchronous motor 1
Stator resistor of
P02.20
synchronous motor 1
Direct axis inductance of
P02.21
synchronous motor 1
Quadrature axis
P02.22 inductance of
synchronous motor 1
P02.23 Back EMF constant of
synchronous motor 1
Multi-function digital input
P05.01~P0
5.09 (S1~S8, HDI) function
P08.31 Motor shifting
P12.00
Rated power of
P12.01
asynchronous motor 2
Rated frequency of
P12.02
asynchronous motor 2
Rated speed of
P12.03
asynchronous motor 2
Rated voltage of
P12.04
asynchronous motor 2
Name Detailed instruction of parameters
1~128
0~1200V
0.8~6000.0A
0.001~65.535Ω
0.01~655.35mH
0.01~655.35mH
0~10000
terminals
35: Shift from motor 1 to motor 2
selection
0: Terminal shifting; digital terminal is 35
1: MODBUS communication shifting
2: PROFIBUS/CANopen communication
shifting
0: Asynchronous motor
Motor 2
1: Synchronous motor
0.1~3000.0kW
0.01Hz~P00.03(the Max. frequency)
1~36000rpm
0~1200V
195
www.barghmaher.ir
Basic operation instruction
Default
value
2
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
300
0
1
Depend
on model
50.00Hz
Depend
on model
Depend
on model
