inverters
Goodrive35
Function
code
P06.21 AO1 output filter time
P06.22 Lower output limit of AO2 -300.0%~P06.24
Corresponding AO2
P06.23
output of lower limit
P06.24 Upper output limit of AO2 P06.18~300.0%
The corresponding AO2
P06.25
output of upper limit
P06.26 AO2 output filter time
P06.27 Lower output limit of HDO -300.0%~P06.29
Corresponding HDO
P06.28
output of lower limit
P06.29 Upper output limit of HDO P06.23~300.0%
Corresponding HDO
P06.30
output of upper limit
P06.31 HDO output filter time

7.11 Digital input

Goodrive35 series inverters have 8 programmable digital input terminals and 1 open circuit
electrode output terminal in the standard configuration. All functions of the digital input terminals
are programmable by the function codes. Open collector pole input can be selected into high
speed pulse input terminal or common switch input terminal by function code. When selected into
HDI, the user can select HDI high speed pulse input as frequency given, counting input or length
pulse input by setting.
Detailed instruction of parameters
Name
0.000s~10.000s
0.00V~10.00V
0.00V~10.00V
0.000s~10.000s
0.00~50.00kHz
0.00~50.00kHz
0.000s~10.000s
211
www.barghmaher.ir
Basic operation instruction
Default
value
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
0.0kHz
100.0%
50.00kHz
0.000s
