INVT Goodrive 35 Series Operation Manual page 58

inverters
Goodrive35
Function
Name
code
3: Reserved
Note: 1, 2 and 3 are extension functions which need
corresponding extension cards.
This parameter is used to set the maximum output
frequency of the inverter. Users should pay attention
Max.
to this parameter because it is the foundation of the
P00.03 output
frequency setting and the speed of acceleration and
frequency
deceleration.
Setting range: P00.04~400.00Hz
The upper limit of the running frequency is the upper
Upper limit
limit of the output frequency of the inverter which is
of the
P00.04 lower than or equal to the maximum frequency.
running
Setting range:P00.05~P00.03 (Max. output
frequency
frequency)
The lower limit of the running frequency is that of the
output frequency of the inverter.
Lower limit The inverter runs at the lower limit frequency if the
of the set frequency is lower than the lower limit one.
P00.05
Note: Max. output frequency ≥ Upper limit frequency
running
≥ Lower limit frequency
frequency
Setting range:0.00Hz~P00.04 (Upper limit of the
running frequency)
A Note: Frequency A and frequency B cannot use the
P00.06 frequency same frequency setting mode. The frequency source
command can be set by P00.09.
0:Keypad
Modify the value P00.10 (set the frequency by
keypad) to modify the frequency by the keypad.
1: AI1
B
2: AI2
P00.07 frequency
3: AI3
command
Set the frequency by analog input terminals.
Goodrive35 series inverters provide 3 analog input
terminals as the standard configuration, of which
Detailed instruction of parameters
57
www.barghmaher.ir
Function codes
Default
Modify
value
50.00
◎
Hz
50.00
◎
Hz
0.00
◎
Hz
○
0
○
2
