INVT Goodrive 35 Series Operation Manual page 97

inverters
Goodrive35
Function
Name
code
Lower limit
P05.50 frequency 0.000kHz~P05.52
of HDI
Correspon
ding
setting of
P05.51 -300.0%~300.0%
HDI low
frequency
setting
Upper limit
P05.52 frequency P05.50 ~50.000kHz
of HDI
Correspon
ding
setting of
P05.53 -300.0%~300.0%
upper limit
frequency
of HDI
HDI
frequency
P05.54 0.000s~10.000s
input filter
time
P06 Group Output terminals
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output: The
HDO Max.pulse frequency is 50.0kHz. See
P06.00
output P06.27~P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
Detailed instruction of parameters
96
www.barghmaher.ir
Function codes
Default
Modify
value
0.000
○
kHz
○
0.0%
50.000
○
kHz
100.0
○
%
○
0.030s
◎
0
