INVT Goodrive 35 Series Operation Manual page 17

inverters
Goodrive35
Function
Analog input
Analog output
Digital input
Digital output
Relay output
Spindle stopping
Position reference
Servo control
Frequency division
output
Speed/position mode
Encoder
Positioning
Mountable method
Temperature of the
running environment
Average non-fault
time
Others
Protective degree
Cooling
Braking unit
2 (AI1, AI2) 0~10V/0~20mA and 1 (AI3) -10~10V
2 (AO1, AO2) 0~10V /0~20mA
8 common inputs, the Max. frequency: 1kHz,
internal impedance: 3.3kΩ;
1 high speed input, the Max. frequency: 50kHz
1 high speed pulse output, the Max. frequency:
50kHz;
1 Y terminal open collector output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
For spindle positioning and control sequence
Internal 7 scale marks and 4 zero marks
External zero-position detection switch positioning
Encoder Z phase positioning
Pulse train reference: position control
Encoder frequency division output
(H1 and H2 inverters)
Terminal shifting
C1 support 100kHz, D1 support 500kHz, H1 support
300kHz and H2 support 400kHz
Z pulse and photoelectric switch positioning
Wall, flange and floor mountable
-10~50℃, if temperature is above 40℃, derate 1%
for every additional 1℃.
2 years (25℃ ambient temperature)
IP20
Air-cooling
Built-in for inverters of 380V(≤30kW)
External for others
