INVT Goodrive 35 Series Operation Manual page 78

inverters
Goodrive35
Function
Name
code
5:Pulse frequency HDI setting torque
6:Multi-step torque setting
7:MODBUS communication setting torque
8:PROFIBUS\CANopen communication setting
torque
9:Ethernet communication setting torque
10:Reserved
Note: Setting modes 2~10, 100% corresponds to
three times of the rated current of the motor.
Keypad
Setting range: -300.0%~300.0%(rated current of the
P03.12 setting
motor)
torque
Torque
P03.13 reference 0.000~10.000s
filter time
Upper 0:Keypad (P03.16 sets P03.14,P03.17 sets P03.15)
frequency
1: AI1
of forward
2: AI2
P03.14
rotation in
3: AI3
vector
4:Pulse frequency HDI setting upper-limit frequency
control
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
Upper
frequency
frequency
7:PROFIBUS/CANopen communication setting
of reverse
upper-limit frequency
P03.15
rotation in
8:Ethernet communication setting upper-limit
vector
frequency
control
Note:Setting method 1~8, 100% corresponds to the
maximum frequency
This function is used to set the upper limit of the
Keypad
P03.16
frequency. P03.16 determines the setting when
setting for
P03.14=1; P03.17 determines the setting when
upper
Detailed instruction of parameters
77
www.barghmaher.ir
Function codes
Default
Modify
value
○
10.0%
○
0.100s
○
0
○
0
50.00
○
Hz
