INVT Goodrive 35 Series Operation Manual page 95

inverters
Goodrive35
Function
Name
code
terminal
Lower limit
The function code defines the relationship between
P05.32
of AI1
the analog input voltage and its corresponding set
Correspon
value. If the analog input voltage beyond the set
ding
minimum or maximum input value, the inverter will
P05.33 setting of
count at the minimum or maximum one.
the lower
When the analog input is the current input, the
limit of AI1
corresponding voltage of 0~20mA is 0~10V.
Upper limit
In different cases, the corresponding rated value of
P05.34
of AI1
100.0% is different. See the application for detailed
Correspon
information.
ding
The figure below illustrates different applications:
P05.35 setting of
the upper
limit of AI1
AI1 input
P05.36
filter time
Lower limit
P05.37
of AI2
Correspon
Input filter time: this parameter is used to adjust the
ding
sensitivity of the analog input. Increasing the value
P05.38 setting of
properly can enhance the anti-interference of the
the lower
analog, but weaken the sensitivity of the analog
limit of AI2
input.
Upper limit
P05.39
Note: Analog AI1 and AI2 can support 0~10V or
of AI2
0~20mA input, when AI1 and AI2 selects 0~20mA
Correspon
input, the corresponding voltage of 20mA is 5V. AI3
ding
can support the output of -10V~+10V.
P05.40 setting of
The setting range of P05.32:0.00V~P05.34
the upper
The setting range of P05.33: -300.0%~300.0%
limit of AI2
Detailed instruction of parameters
94
www.barghmaher.ir
Function codes
Default
Modify
value
○
0.00V
○
0.0%
10.00
○
V
100.0
○
%
○
0.030s
○
0.00V
○
0.0%
10.00
○
V
100.0
○
%
