INVT Goodrive 35 Series Operation Manual page 204

inverters
Goodrive35
Function
code
B frequency command
P00.08
Combination of the setting
P00.09
Multi-function digital input
P05.01~P0
5.09 (S1~S8,HDI) function
P08.42 Keypad data control
Name Detailed instruction of parameters
3: AI3
4:High-speed pulse HDI setting
5:Simple PLC program setting
6: Multi-step speed running setting
7: PID control setting
8:MODBUS communication setting
9:PROFIBUS/CANopen communication
setting
10:Ethernet communication
setting(reserved)
11:Reserved
0: Maximum output frequency
reference 1: A frequency command
0:A
1:B
2:(A+B)combination
source 3:(A-B)combination
4:Max(A,B)combination
5:Min(A,B)combination
10:Increasing frequency setting (UP)
11:Decreasing frequency setting
(DOWN)
12:Cancel the frequency change setting
terminals
13:Shift between A setting and B setting
14:Shift between combination setting
selection
and A setting
15:Shift between combination setting
and B setting
0x000~0x1223
LED ones:frequency enable selection
0:Both ∧/∨ keys and digital
potentiometer adjustments are valid
1:Only ∧/∨ keys adjustment is valid
2:Only digital potentiometer adjustments
www.barghmaher.ir
Basic operation instruction
203
Default
value
0
0
0x0000
