inverters
Goodrive35
Function
code
P05.44 Zero-drift value of AI3
Zero-point deadzone
P05.45
voltage of AI3
P05.46 Upper limit of AI3
Corresponding setting of
P05.47
the upper limit of AI3
P05.48 AI3 input filter time
HDI high-speed pulse
P05.49
input function
Lower limit frequency of
P05.50
Corresponding setting of
P05.51
HDI low frequency setting
Upper limit frequency of
P05.52
Corresponding setting of
P05.53 upper limit frequency of
HDI frequency input filter
P05.54

7.10 Analog output

Goodrive35 series inverters have 2 analog output terminals (0~10V or 0~20mA) and 1 high speed
pulse output terminal. Analog output signal can be filtered and the maximum and minimum values
can be adjusted. The analog output signals can be proportional to motor speed, output frequency,
output current, motor torque, motor power, etc. 100% of the output current is relative to 2 times of
the rated current of the inverter.
Name Detailed instruction of parameters
P05.42~P05.46
0.00~10.00V
P05.35~10.00V
-300.0%~300.0%
0.000s~10.000s
0:Frequency setting input, frequency
setting source
1:Counter input, high-speed pulse
counter input terminals
selection
2:Length counting input, length counter
input terminals
0.00 kHz ~ P05.43
HDI
-300.0%~300.0%
P05.41~50.00kHz
HDI
-300.0%~300.0%
HDI
0.000s~10.000s
time
207
www.barghmaher.ir
Basic operation instruction
Default
value
0.00V
0.04V
10.00V
100.0%
0.030s
0
0.00kHz
0.0%
50.00kHz
100.0%
0.030s
