INVT Goodrive 35 Series Operation Manual page 215

inverters
Goodrive35
Set
value
16 Multi-step speed terminal 1
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1
22 ACC/DEC time selection 2
23 Simple PLC stop reset
24 Simple PLC pause
25 PID control pause
Traverse pause (stop at the
26
current frequency)
27 Traverse reset (return to the
Function
The 15
frequency given channel and the combination setting
channel set by P00.09
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: multi-step speed 1 is the low bit; multi-step
speed 4 is the high bit.
Multi-step
speed 4
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
terminals.
Terminal
OFF
OFF
Restart simple PLC and clear the memory state of
PLC.
Program pause during PLC implement. Run at the
current speed stage. After cancel the function, simple
PLC continues to run.
Temporal PID invalid and the inverter will output at the
current frequency.
The inverter will stop at the current output and after
canceling the function, the inverter will continue to
traverse run at the current frequency.
The setting frequency of the inverter will come back to
www.barghmaher.ir
Instructions
th
function can realize the shifting between B
Multi-step
speed 3
BIT3 BIT2
Terminal ACC/DEC time
1 2 selection
OFF ACC/DEC time 1 P00.11/P00.12
ON OFF ACC/DEC time 2 P08.00/P08.01
ON ACC/DEC time 3 P08.02/P08.03
ON ON ACC/DEC time 4 P08.04/P08.05
214
Basic operation instruction
Multi-step Multi-step
speed 2 speed 1
BIT1 BIT0
Corresponding
parameter
