Function
Name
code
cycle. The longer the sapling cycle is, the slower the
response is.
Setting range: 0.001~1.000s
The output of PID system is the maximum deviation
relative to close loop reference. As shown in the
diagram below, PID adjustor stops to work during the
deviation limit. Set the function properly to adjust the
accuracy and stability of the system.
PID control
P09.08 deviation
limit
Setting range:0.0~100.0%
Output This parameter is used to set the upper and lower
P09.09 upper limit
limit of the PID adjustor output.
of PID 100.0 % corresponds to max. frequency or the max.
Output voltage of ( P04.31)
P09.10 lower limit Setting range of P09.09: P09.10~100.0%
Setting range of P09.10: -100.0%~P09.09
of PID
Detection
value of Set the detection value of feedback offline, when the
P09.11
feedback
feedback detection value is smaller than or equals to
offline
the detected value, and the lasting time exceeds the
set value in P09.12, the inverter will report "PID
Detection
time of feedback offline fault" and the keypad will display
P09.12
feedback PIDE.
offline
Detailed instruction of parameters
124
