Goodrive35
No.
Name
Mean the unit displayed currently
2
Unit LED
5-figure LED display displays various monitoring data and alarm code such
as set frequency and output frequency.
Displayed
Code
word
3
displaying
zone
Description
LOCAL/REMOT
TRIP
Correspo
Displayed
nding
word
word
0
3
6
48
www.barghmaher.ir
Keypad operation procedure
forward rotation state; LED on means
the inverter is in the reverse rotation
state
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the inverter is in the
keypad operation state; LED blinking
means the inverter is in the terminals
operation state; LED on means the
inverter is in the remote communication
control state.
LED for faults
LED on when the inverter is in the fault
state; LED off in normal state; LED
blinking means the inverter is in the
pre-alarm state.
Hz
Frequency unit
RPM
Rotating speed unit
A
Current unit
%
Percentage
V
Voltage unit
Correspo
Displayed
nding
word
word
1
4
7
Correspo
nding
word
2
5
8
