INVT Goodrive 35 Series Operation Manual page 151

inverters
Goodrive35
Function
Name
code
Output Display current output current of the inverter
P17.04
current Range: 0.0~5000.0A
Motor Display the rotation speed of the motor.
P17.05
speed Range: 0~65535RPM
Torque Display current torque current of the inverter
P17.06
current Range: -3000.0~3000.0A
Exciting Display current exciting current of the inverter
P17.07
current Range: -3000.0~3000.0A
Display current power of the motor.
Motor
P17.08 Setting range: -300.0%~300.0%
power
(the rated current of the motor)
Output Display the current output torque of the inverter.
P17.09
torque Range: -250.0~250.0%
Evaluated Evaluate the motor rotor frequency on close loop
P17.10 motor vector
frequency Range: 0.00~ P00.03
DC bus Display current DC bus voltage of the inverter
P17.11
voltage Range: 0.0~2000.0V
Display current Switch input terminals state of the
inverter
Digital
input
P17.12
terminals
state
Range: 0000~01FF
Display current Switch output terminals state of the
Digital
inverter
output
P17.13
terminals
state
Range: 0000~000F
Digital Display the adjustment through the keypad of the
P17.14
adjustment inverter.
Detailed instruction of parameters
BIT8 BIT7
HDI S8
BIT4 BIT3 BIT2
S5 S4 S3
BIT3 BIT2
RO2 RO1
150
www.barghmaher.ir
Function codes
Default
BIT6 BIT5
S7 S6
BIT1 BIT0
S2 S1
BIT1 BIT0
HDO Y
Modify
value
●
0.0A
●
0 RPM
●
0.0A
●
0.0A
●
0.0%
●
0.0%
0.00
●
Hz
●
0.0V
●
0
●
0
0.00
●
Hz
