  • Page 1 Goodrive100-PV Series Solar Pumping Inver ter...

  • Page 2: Table Of Contents

    Goodrive100-PV series solar pumping inverters Contents Contents Contents ........................... 1 1 Safety precautions ....................... 3 1.1 Safety definition ......................3 1.2 Warning symbols ......................3 1.3 Safety guidelines ......................4 2 Product overview........................6 2.1 Unpacking inspection ....................6 2.2 Name plate ........................6 2.3 Type designation key .....................
  • Page 3 Goodrive100-PV series solar pumping inverters Contents A.4 Reactors ........................69 A.5 Filters........................... 70 Appendix B Recommended solar modules ................ 71 B.1 Recommended configuration for solar pumping inverters .......... 71 B.2 Recommended configuration for inverters with the boost module ......72 Appendix C Inverter mains &...

  • Page 4: Safety Precautions

    Goodrive100-PV series solar pumping inverters Safety precautions 1 Safety precautions Please read this manual carefully and follow all safety precautions before moving, installing, operating and servicing the inverter. If ignored, physical injury or death may occur, or damage may occur to the devices. If any physical injury or death or damage to the devices occurs for ignoring to the safety precautions in the manual, our company will not be responsible for any damages and we are not legally bound in any manner.

  • Page 5: Safety Guidelines

    Goodrive100-PV series solar pumping inverters Safety precautions 1.3 Safety guidelines  Only qualified electricians are allowed to operate on the inverter.  Do not carry out any wiring and inspection or changing components when the power supply is applied. Ensure all input power supply is disconnected before wiring and checking and always wait for at least the time designated on the inverter or until the DC bus voltage is less than 36V.
  • Page 6 Goodrive100-PV series solar pumping inverters Safety precautions  (+) and (-) are DC power supply input terminals. R, S and T (L,N) are AC power supply input terminals. U, V and W are output terminals. Please connect the input power cables and motor cables with proper techniques;...

  • Page 7: Product Overview

    INVT offices. 2. Check the information on the type designation label on the outside of the package to verify that the drive is of the correct type. If not, please contact with local dealers or INVT offices.

  • Page 8: Product Specifications

    Goodrive100-PV series solar pumping inverters Product overview Sign Description Remarks Product Product ① GD100 is short for Goodrive100. abbreviation abbreviation Power range 5R5G—5.5kW ② Rated power + Load type G—Constant torque load 4: AC 3PH 380V(-15%)~440(+10%) 2: AC 3PH 220V(-15%)~240(+10%) Voltage Voltage ③...

  • Page 9: Rated Specifications

    15.7 GD100-2R2G-S2-PV GD100-004G-2-PV GD100-5R5G-2-PV (4-7.5kW) GD100-7R5G-2-PV GD100-0R7G-4-PV 0.75 GD100-1R5G-4-PV GD100-2R2G-4-PV GD100-004G-4-PV 13.5 GD100-5R5G-4-PV 19.5 GD100-7R5G-4-PV 18.5 GD100-011G-4-PV GD100-015G-4-PV GD100-018G-4-PV 18.5 (0.75-110kW) GD100-022G-4-PV GD100-030G-4-PV GD100-037G-4-PV GD100-045G-4-PV GD100-055G-4-PV GD100-075G-4-PV GD100-090G-4-PV GD100-110G-4-PV Note: If you need the inverters >37kW, contact INVT for customization.

  • Page 10: Installation Guidelines

    Goodrive100-PV series solar pumping inverters Installation guidelines 3 Installation guidelines The chapter describes the mechanical installation and electric installation.  Only qualified electricians are allowed to carry out what described in this chapter. Please operate as the instructions in Safety precautions. Ignoring these may cause physical injury or death or damage to the devices.
  • Page 11 Goodrive100-PV series solar pumping inverters Installation guidelines Environment Conditions The installation site of the inverter should: keep away from the electromagnetic radiation source; keep away from contaminative air, such as corrosive gas, oil mist and Running flammable gas; environment ensure foreign objects, such as metal power, dust, oil, water cannot condition enter into the inverter(do not install the inverter on the flammable materials such as wood);...

  • Page 12: Standard Wiring

    Goodrive100-PV series solar pumping inverters Installation guidelines Note: The minimum space of A and B is 100mm. H is 36.6mm and W is 35.0mm. (2) The inverters ≥ 4kW support wall mounting and flange mounting. Flange installation Wall mounting Figure 3-2 installation manners 1) Mark the locations of installation holes.
  • Page 13 Goodrive100-PV series solar pumping inverters Installation guidelines PV input Forced switch to mains Single/two phase algorithm shifting Common terminal High water level switch GD100-PV Low water level inverter switch Common terminal Well Water tower Water pump Figure 3-3 Standard wiring diagram ...
  • Page 14 Goodrive100-PV series solar pumping inverters Installation guidelines Terminals of main circuit Terminal Name Function 3PH (1PH) AC input terminals, connected to the grid R, S, T AC input Note: Use the screws equipped with the inverter for (L, N) wiring. (+), (-) PV input Solar cell panel input terminals...
  • Page 15 Goodrive100-PV series solar pumping inverters Installation guidelines U1 and V1 are the common terminals of the windings. Connect them to the output terminal W of the solar pumping inverter. Connect U2 to the output terminal U of the inverter. Connect V2 to the output terminal V of the inverter.
  • Page 16 Goodrive100-PV series solar pumping inverters Installation guidelines Terminal Category Terminal name Terminal function symbol switching keypad.) S2: It connects to the high-water switch of the normally open contact by default. S3: It connects to the low-water switch of the normally closed contact.

  • Page 17: Keypad Operation Procedure

    Goodrive100-PV series solar pumping inverters Keypad operation procedure 4 Keypad operation procedure 4.1 Keypad introduction Keypads are used to control GD100-PV series inverters, read the state data and adjust parameters. If external keypads are needed, select keypad extension wires. Figure 4-1 Keypad diagram for inverters ≤ 2.2kW Figure 4-2 Keypad diagram for inverters ≥...
  • Page 18 Goodrive100-PV series solar pumping inverters Keypad operation procedure Serial Name Description LED on means the inverter is in the running state. FED/REV LED LED off means the inverter is in the forward FWD/REV rotation state; LED on means the inverter is in the reverse rotation state.

  • Page 19: Keypad Displaying

    Goodrive100-PV series solar pumping inverters Keypad operation procedure Serial Name Description Enter or escape from the first level menu Programming key and remove the parameter quickly. Enter the menu step-by-step. Entry key Confirm parameters. Increase data or function code UP key progressively.
  • Page 20 Goodrive100-PV series solar pumping inverters Keypad operation procedure 4.2.1 Displayed state of stopping parameters When the inverter is in the stopping state, the keypad will display stopping parameters as shown in figure 4-2. In the stopping state, various kinds of parameters can be displayed. Select the parameters to be displayed or not by P07.07.

  • Page 21: Keypad Operation

    Goodrive100-PV series solar pumping inverters Keypad operation procedure Figure 4-3 Displayed state 4.3 Keypad operation Operate the inverter via operation panel. See the detailed structure description of function codes in the brief diagram of function codes. 4.3.1 How to modify the function codes of the inverter The inverter has three levels menu, which are: 1.
  • Page 22 Goodrive100-PV series solar pumping inverters Keypad operation procedure “0.0.0.0.0” will be displayed. Unless using the correct password, the operators cannot enter it. Set P07.00 to 0 to cancel password protection function. The password protection becomes effective instantly after retreating from the function code editing state.

  • Page 23: Commissioning Guidelines

    Goodrive100-PV series solar pumping inverters Commissioning guidelines 5 Commissioning guidelines  Disconnect all power supplies applied to the inverter before the terminal wiring and wait for at least the designated time after disconnecting the power supply.  High voltage is present inside the inverter during running. Do not carry out any operation except for the keypad setting.
  • Page 24 Goodrive100-PV series solar pumping inverters Commissioning guidelines properly. The bigger PI parameters, the stronger the effect is, but the frequency fluctuation of the motor is bigger. In reserve, the lower the water yield is, the more stable the motor frequency is. 5.4.2 Special settings for single phase motors a) When the single phase motor is in bad running performance, the user can adjust P04 VF curve settings: set P04.00=1 and set P04.03~P04.08 to appropriate values according to...

  • Page 25: Function Parameters

    Goodrive100-PV series solar pumping inverters Function parameters 6 Function parameters ○ “ ”: means the set value of the parameter can be modified on stop and running state; “◎”: means the set value of the parameter cannot be modified on the running state; ●...
  • Page 26 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code includes: start, stop, forward/reverse rotating, jogging and fault reset. 0: Keypad running command channel(“LOCAL/REMOT” light off) Carry out the command control by RUN, STOP/RST on the keypad. Set the multi-function key QUICK/JOG to FWD/REV shifting function (P07.02=3) to change the running direction;...
  • Page 27 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code The upper limit of the running frequency is the upper limit of the output frequency of Upper limit of the the inverter which is lower than or equal to ◎...
  • Page 28 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 0: Runs at the default direction. The inverter runs in the forward direction. FWD/REV indicator is off. 1: Runs at the opposite direction. The inverter runs in the reverse direction.
  • Page 29 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code autotune. It is recommended to use rotation autotuning when high control accuracy is needed. 2: Static autotuning It is suitable in the cases when the motor cannot de-couple form the load.
  • Page 30 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 1: Coast to stop. After the stop command becomes valid, the inverter ceases the output immediately. And the load coasts to stop at the mechanical inertia. 0: The terminal running command is Operation invalid when powering on.
  • Page 31 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code parameter autotuning comes from the correct setting of the motor name plate. In order to ensure the controlling performance, please configure the motor according to the Rated current of standard principles, if Depend...
  • Page 32 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code motor by vectors which Mutual inductance directly impact the Depend ○ P02.09 of asynchronous 0.1~6553.5mH features. on model motor Note: Users cannot Non-load current modify the parameters Depend ○...
  • Page 33 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code frequency. Output voltage 1.3th power low torque V/F curve 1.7 t h power low torque V/F curve Linear type 2.0th power low torque V/F curve Square type Output...
  • Page 34 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Output voltage 提升 截至 Output frequency Setting range of P04.01: 0.0%: (automatic) 0.1%~10.0% Setting range of P04.02: 0.0%~50.0% If P04.00 =1, the user can set V//F curve ○...
  • Page 35 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code motor1) or P04.05~P02.16(rated frequency of motor1) Setting range of P04.08: 0.0%~110.0% (rated voltage of motor1) This function code is used to compensate the change of the rotation speed caused by load during compensation SVPWM control to improve the rigidity of the motor.
  • Page 36 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code P05 Group Input terminals 0: High-speed pulse input. See ◎ P05.00 HDI input type P05.49~P05.54. 1: HDI switch input S1 terminals 0: No function ◎...
  • Page 37 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 22: ACC/DEC time 2 23: Simple PLC stop reset 24: Simple PLC pause 25: PID control pause 26: Traverse pause (stop at the current frequency) 27: Traverse reset (return to the center frequency)
  • Page 38 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 45: Two-phase control mode of the single-phase motor 46: Boost module-free PV digital input (for auto switching) 47~63: Reserved Polarity selection 0x000~0x10F ◎ P05.10 0x000 of the input BIT8...
  • Page 39 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 19: Defined count value arrival 20: External fault valid 21: Reserved 22: Running time arrival 23: MODBUS communication virtual terminals output 24~26: Reserved 27: Weak light 28~29: Reserved 30: Shift to PV mode (If the system works in PV mode, relay output is high.)
  • Page 40 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Switch off delay of ○ P06.13 0.000s 0.000~50.000s P07 Group Human-Machine Interface 0: No function 1: Jogging running. Press QUICK/JOG to begin the jogging running. 2: Shift the display state by the shifting key.
  • Page 41 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code will run according to parameter P00.13 during next powering on. When P07.02=6, set the shifting sequence of running command channels. 0: Keypad control→terminal control QUICK/JOG the →communication control shifting sequence...
  • Page 42 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code temperature MSB of inverter Display the power used by the inverter. ● P07.15 power Inverter power consumption consumption=P07.15*1000+P07.16 Setting range of P07.15: 0~65535(*1000) LSB of inverter ●...
  • Page 43 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Previous 11 fault 20:Motor antotune fault(tE) ● P07.62 type 21: EEPROM operation fault(EEP) 22: PID response offline fault(PIDE) Previous 12 fault ● P07.63 23: Braking unit fault(bCE) type 24: Running time arrival(END) Previous 13 fault...

  • Page 44: Parameters Of Special Functions

    Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Weak light alarm (A-LS) Underload alarm (A-LL) Full water alarm (A-tF) Water-empty alarm (A-tL) P08 Group Enhanced functions Times of fault ○ P08.28 0~10 reset Interval time of ○...
  • Page 45 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Frequency 0: Disable ○ P11.01 decrease at 1: Enable sudden power loss Setting range: 0.00Hz~P00.03/s After the power loss of the grid, the bus voltage drops to the sudden frequency decrease point, the inverter begin to decrease the running frequency at...
  • Page 46 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 1 means to apply the reference voltage of Max. power tracking. The voltage is changing until the system is stable. Note: If terminal 43 is valid, the function is invalid.
  • Page 47 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code cannot exceed the upper limit. 0.0%~P15.04 (100.0% corresponds to P00.03) P15.05 is used to limit the Min. value of Lower frequency ○ P15.05 20.0% target frequency, and 100.0% of PI output corresponds to P00.03.
  • Page 48 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 0.0~6553.5Vdc If the absolute value of bus voltage minus the reference value is bigger than ◎ P15.10 PI switching point 20.0V P15.10, it will switch to P15.08 and P15.09;...
  • Page 49 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code If the function code is 1~3, it is the reference of water-level control analog signal. For details, see P15.12 and P12.13. 0.0~100.0% This code is valid when P15.11 water level control is based on analog input.
  • Page 50 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 0.0~100.0% This code is valid when P15.11 water level control is based on analog input. If the detected water level control analog signal is greater than the water level threshold P15.13 and keeps in the state after the delay time P15.16, the system reports A- tL and sleeps.
  • Page 51 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Time setting of wake-up delay in full-water state (This function code is still valid when the digital indicates the full-water signal.) 0~10000s Time setting of empty-water delay (This ○...
  • Page 52 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code light alarm without any delay time. If P15.32=0, the system will switch to the mains input when the light is weak. 0.0~3600.0s Delay time of wake-up at weak light If the weak light alarm is reported, after Delay time of the delay time of wake-up, the alarm will...
  • Page 53 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code Min. voltage reference during max. power tracking~P15.31 Valid in MPPT Max. tracking voltage, the tracked max. voltage Max. voltage The default value depends on model. reference during ○...
  • Page 54 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code upper and lower Adjustment of the upper and lower limits limits of Vmppt P15.27~6553.5V The upper limit cannot exceed the P15.28 when Vmppt is the maximum value.
  • Page 55 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code input through the relay output. If the value is 0, it is invalid. For inverters without the boost module, the switching point voltage is determined by the external voltage detection circuit.
  • Page 56 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code PV UV Model point -SS2 140V 140V 140V 240V Any model with the boost module Setting range: 0.0~400.0 This function code is provided for users to change models.
  • Page 57 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code secondary winding when applying capacitance-removing to control the single phase motor. 0.00~100.00A P18 Group State viewing special for solar converters MPPT is implemented at the converter PV reference ●...
  • Page 58 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code 1: Detection indicates the system does not contain the boost module. ● P18.11 Current pump flow Unit: cubic meter/hour ● P18.12 Current pump lift Unit: meter This function code displays the 16 most MSBs in total pump ●...
  • Page 59 Goodrive100-PV series solar pumping inverters Function parameters Function Name Detailed illustration of parameters Default Modify code P19.05~15.0A This function code is set to the bus reference voltage at PV input when the system contains the boost module. By Bus reference ◎...
  • Page 60 Goodrive100-PV series solar pumping inverters Function parameters  Delay time counting follows the rules if multiple fault conditions are met simutaneously: For example, if all fault conditions of weak light, full water, and underload are met at the same time, the inverter will count the delay time for each fault independently. If the delay time of a fault is reached, the fault is reported.

  • Page 61: Fault Diagnosis And Solution

    Do as follows after the inverter encounters a fault: 1. Check to ensure there is nothing wrong with the keypad. If not, please contact with the local INVT office. 2. If there is nothing wrong, please check P07 and ensure the corresponding recorded fault parameters to confirm the real state when the current fault occurs by all parameters.
  • Page 62 Goodrive100-PV series solar pumping inverters Fault diagnosis and solution Fault Fault type Possible cause Solutions code too low. circuited (the grounding short 4. The load transients or is circuited or the wire short abnormal. circuited) or the rotation is not 5.
  • Page 63 Goodrive100-PV series solar pumping inverters Fault diagnosis and solution Fault Fault type Possible cause Solutions code 2. Ambient temperature is too change the fan. high. 2. Decrease the environment IGBT overheat 3. The time of overload temperature. running is too long. SI external fault input External fault Check the external device input.
  • Page 64 Goodrive100-PV series solar pumping inverters Fault diagnosis and solution Fault Fault type Possible cause Solutions code 2. The PID feedback source 2. Check the PID feedback disappears. source. The actual running time of the Time arrival of Ask for the supplier and adjust inverter is above the internal factory setting the setting running time.
  • Page 65 Goodrive100-PV series solar pumping inverters Fault diagnosis and solution Fault Fault type Possible cause Solutions code Change the wiring direction of PV reverse the positive and negative PINV Incorrect PV wiring connection fault terminals and connect the cables again. 1. The acceleration or 1.
  • Page 66 Goodrive100-PV series solar pumping inverters Fault diagnosis and solution Fault Fault type Possible cause Solutions code panel configuration is proper. A-LL Underload alarm The reservoir is empty. Check the reservoir. If the user has set the full-water alarm function, the equipment automatically stops when the full-water alarm time reaches the A-tF...

  • Page 67: Appendix A Options And Use

    Goodrive100-PV series solar pumping inverters Options and use Appendix A Options and use A.1 Boost module The pumping inverters ≤ 2.2KW support the installation of the boost module (PP100-3R2-PV) to improve the utilization of the solar modules. The figure below shows the wiring method. Connect PV+ and PV- of the boost module to the positive input terminal and negative input terminal of the modules respectively.

  • Page 68: Gprs Module And Monitoring App

    Goodrive100-PV series solar pumping inverters Options and use Instruction of LEDs Display state Description The boost module has been powered on, and the control Green LED flickering circuit is working. Green LED on The boost module is running. Red LED on The boost module is faulty.

  • Page 69: Cables

    Goodrive100-PV series solar pumping inverters Options and use For more information, see the GPRS/GPS adaptor operation guide matching the GPRS module or contact the local INVT office. When consulting, provide the product models and serial numbers. A.3 Cables A.3.1 Power cables Dimension the input power and motor cables according to local regulations.

  • Page 70: Reactors

    If the distance between the inverter and motor is 50~100m, see the table below for model selection; if it exceeds 100m, consult with INVT technical support. Output reactor model selection Inverter power...

  • Page 71: Filters

    Goodrive100-PV series solar pumping inverters Options and use Inverter power Output reactor GD100-5R5G-2-PV OCL20A03504-1 GD100-7R5G-2-PV OCL40A01804-1 GD100-0R7G-4-PV OCL5A14004-1 GD100-1R5G-4-PV OCL5A14004-1 GD100-2R2G-4-PV OCL7A10004-1 GD100-004G-4-PV OCL10A07004-1 GD100-5R5G-4-PV OCL15A04704-1 GD100-7R5G-4-PV OCL20A03504-1 GD100-011G-4-PV OCL30A02304-1 GD100-015G-4-PV OCL40A01804-1 GD100-018G-4-PV OCL50A01404-1 GD100-022G-4-PV OCL60A01204-1 GD100-030G-4-PV OCL80A00874-1 GD100-037G-4-PV OCL90A00784-1 Note: The rated derate voltage of the output reactor is 1%±15%.

  • Page 72: Appendix B Recommended Solar Modules

    Open-circuit voltage degree of solar module 37±1V 45±1V Solar pumping inverter Modules per model Module Module Modules per string * power±5Wp power±5Wp string * strings strings GD100-0R4G-SS2-PV 11*1 GD100-0R7G-SS2-PV 11*1 GD100-1R5G-SS2-PV 11*1 GD100-2R2G-SS2-PV 11*1 GD100-0R4G-S2-PV 11*1 GD100-0R7G-S2-PV 11*1 GD100-1R5G-S2-PV 11*1...

  • Page 73: Recommended Configuration For Inverters With The Boost Module

    Open-circuit voltage degree of solar module PP100-3R2-PV input 37±1V 45±1V current Solar pumping Module Modules per Module Modules per inverter power±5Wp string * strings power±5Wp string * strings GD100-0R4G-SS2-PV GD100-0R7G-SS2-PV GD100-1R5G-SS2-PV GD100-0R4G-S2-PV GD100-0R7G-S2-PV GD100-1R5G-S2-PV GD100-0R7G-4-PV GD100-1R5G-4-PV GD100-2R2G-4-PV 13*1 11*1 -72-...

  • Page 74: Appendix C Inverter Mains & Pv Switching Solution

    SPD(Surge Protection Device) Figure C-1 Inverter mains & PV switching solution Note: For the specifications and model selection of QH100-PV switching module, consult INVT local office. C.1.1 QH100-PV switching module C.1.1.1 Models and specifications QH100 – 055A – 4 – PV ①...
  • Page 75 Goodrive100-PV series solar pumping inverters Inverter mains & PV switching solution Sign Description Remarks 055A: applies to inverters ≤15kW Rated ② Inverter power current 110A: applies to inverters 18.5~37kW Voltage 4: AC 3PH 380V(-15%)~440(+10%) ② Voltage degree degree 2: AC 3PH 220V(-15%)~240(+10%) Industrial ④...
  • Page 76 Goodrive100-PV series solar pumping inverters Inverter mains & PV switching solution C.1.1 Model selection reference for low-voltage apparatus Diode Model breaker breaker contactor Fuse GD100-0R4G-S2-PV-AS GD100-0R7G-S2-PV-AS GD100-0R4G-SS2-PV-AS Type Ⅱ, GD100-1R5G-S2-PV-AS 1000V GD100-0R7G-SS2-PV-AS 25A/16 GD100-2R2G-S2-PV-AS 16A/ 1000VDC GD100-1R5G-SS2-PV-AS GD100-2R2G-SS2-PV-AS GD100-0R7G-4-PV-AS GD100-1R5G-4-PV-AS...

  • Page 77: Ip54 Protection-Level Inverters

    Inverter mains & PV switching solution C.2 IP54 protection-level inverters INVT provides IP54 protection-level inverters, which are divided into two types: One type implements auto mains & PV switching and the other type does not implement auto switching. The figure below shows the inverter dimensions.

  • Page 78: Wiring Terminals

    Goodrive100-PV series solar pumping inverters Inverter mains & PV switching solution Power (kW) Model GD100-2R2G-45-PV-AS GD100-2R2G-S25-PV-AS GD100-2R2G-SS25-PV-AS GD100-1R5G-45-PV-AS GD100-1R5G-S25-PV-AS GD100-1R5G-SS25-PV-AS GD100-0R7G-45-PV-AS 0.75 GD100-0R7G-S25-PV-AS GD100-0R7G-SS25-PV-AS GD100-0R4G-S25-PV-AS GD100-0R4G-SS25-PV-AS Note: 1. The inverters that do not implement auto switching do not have the suffix -AS. 2.

  • Page 79: Parameter Setting Method

    Goodrive100-PV series solar pumping inverters Inverter mains & PV switching solution Figure C-4 Wiring terminals of -4 models for inverters ≤2.2kW Figure C-5 Wiring terminals of -S2/-SS2 models for inverters ≤2.2kW Wiring terminal functions Terminal Name Function 3PH 380/220V AC input terminals, connected to the grid R, S, T Neutral wire.

  • Page 80: Appendix D Dimension Drawings

    Goodrive100-PV series solar pumping inverters Dimension drawings Appendix D Dimension drawings D.1 External keypad structure Keypad structure Installation hole Note: The external keypad is optional for the inverters (380V; ≤2.2kW) and the standard keypad of inverters (380V; ≥4kW) can be used as the external keypad. If the keypad is externally installed on an optional bracket, it can be 20 meters away from the inverter at most.

  • Page 81: Dimensions Of 0.4-2.2Kw Models

    Dimensions in wall mounting (unit: mm) Installation Model hole (d) GD100-0R4G-S2-PV 80.0 60.0 160.0 150.0 123.5 120.3 GD100-0R7G-S2-PV 80.0 60.0 160.0 150.0 123.5 120.3 GD100-0R4G-SS2-PV 80.0 60.0 160.0 150.0 123.5 120.3 GD100-1R5G-S2-PV 80.0 60.0 185.0 175.0 140.5 137.3 GD100-2R2G-S2-PV 80.0 60.0 185.0 175.0...
  • Page 82 Dimensions in rail mounting (unit: mm) Installation Model hole (d) GD100-0R4G-S2-PV 80.0 160.0 35.4 36.6 123.5 120.3 GD100-0R7G-S2-PV 80.0 160.0 35.4 36.6 123.5 120.3 GD100-0R4G-SS2-PV 80.0 160.0 35.4 36.6 123.5 120.3 GD100-1R5G-S2-PV 80.0 185.0 35.4 36.6 140.5 137.3 GD100-2R2G-S2-PV 80.0 185.0 35.4 36.6...

  • Page 83: Dimensions Of 4-37Kw Models

    Goodrive100-PV series solar pumping inverters Dimension drawings D.3 Dimensions of 4-37kW models (a) Wall mounting Dimensions in wall mounting (unit: mm) Installation Model hole (d) GD100-004G-4-PV 146.0 131.0 256.0 243.5 167.0 84.5 GD100-5R5G-4-PV 146.0 131.0 256.0 243.5 167.0 84.5 GD100-7R5G-4-PV 170.0 151.0 320.0...
  • Page 84 Goodrive100-PV series solar pumping inverters Dimension drawings (b) Flange installation Dimensions in flange installation (unit: mm) Installation Model W1 W2 W3 W4 H1 hole specs GD100-004G-4-PV 170.2 131 150 9.5 292 276 260 167 84.5 GD100-5R5G-4-PV 170.2 131 150 9.5 292 276 260 167 84.5 GD100-7R5G-4-PV 191.2 151 174 11.5 370 351 324 12 196.3 113 GD100-011G-4-PV 191.2 151 174 11.5 370 351 324 12 196.3 113...

  • Page 85: Appendix E Further Information

    E.1 Product and service inquiries Address any inquiries about the product to your local INVT offices, quoting the type designation and serial number of the unit in question. A listing of INVT sales, support and service contacts can be found by navigating to www.invt.com.cn.
