INVT Goodrive 35 Series Operation Manual page 105

inverters
Goodrive35
Function
Name
code
0x0000~0xFFFF
BIT0:running frequency (Hz on)
BIT1:set frequency(Hz flickering)
BIT2:bus voltage (Hz on)
BIT3:output voltage(V on)
BIT4:output current(A on)
BIT5:running rotation speed (rpm on)
BIT6:output power(% on)
Parameter
P07.05 BIT7:output torque(% on)
s state 1
BIT8:PID reference(% flickering)
BIT9:PID feedback value(% on)
BIT10:input terminals state
BIT11:output terminals state
BIT12:torque set value(% on)
BIT13:pulse counter value
BIT14:length value
BIT15:PLC and the current stage in multi-step speed
0x0000~0xFFFF
BIT0: AI1 (V on)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
Parameter
P07.06 BIT4: motor overload percentage (% on)
s state 2
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency given value(Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9~15:reserved
Parameter 0x0000~0xFFFF
s for BIT0:set frequency(Hz on, frequency flickering
P07.07
stopping slowly)
state BIT1:bus voltage (V on)
Detailed instruction of parameters
104
www.barghmaher.ir
Function codes
Default
Modify
value
0x03F
○
F
0x000
0
0x00F
○
F
