INVT Goodrive 35 Series Operation Manual page 152

inverters
Goodrive35
Function
Name
code
Range : 0.00Hz~P00.03
Display the torque given, the percentage to the
Torque current rated torque of the motor.
P17.15
reference Setting range: -300.0%~300.0%(the rated current of
the motor)
AI1
P17.16 adjustment 0.00~10.00V
voltage
AI2
P17.17 adjustment 0.00~10.00V
voltage
AI3
P17.18 adjustment 0.00~10.00V
voltage
AI1 input Display analog AI1 input signal
P17.19
voltage Range: 0.00~10.00V
AI2 input Display analog AI2 input signal
P17.20
voltage Range: 0.00~10.00V
AI3 input Display analog AI2 input signal
P17.21
voltage Range: -10.00~10.00V
HDI input Display HDI input frequency
P17.22
frequency Range: 0.00~50.00kHz
PID Display PID given value
P17.23
reference Range: -100.0~100.0%
PID Display PID response value
P17.24
feedback Range: -100.0~100.0%
Power
Display the current power factor of the motor.
P17.25 factor of
Range: -1.00~1.00
the motor
Current Display the current running time of the inverter.
P17.26
running Range:0~65535min
Detailed instruction of parameters
151
www.barghmaher.ir
Function codes
Default
Modify
value
●
0.0%
●
0.00V
●
0.00V
●
0.00V
●
0.00V
●
0.00V
●
0.00V
0.00
●
kHz
●
0.0%
●
0.0%
●
0.00
●
0min
